Concealed Frame NFR Pocket Door Kit

Concealed Frame Pocket Door Kit Only

- Door Leaf Not Included

- Non Fire Rated

- 120mm double boarded wall build up as standard, plasterboard to plasterboard.

- Option for double boarded 145mm kits available on request (recommended for doors over 2.2m tall)

Included in your kit:

- Enigma Pocket Door Kit

- White Primed Metal Plaster In Trims

- Self Lubricating Running Gear and Track for doors up to 140kg

- Guide Pin & Chanel

- Door Stops (in track stops), including remote stop for easy installation

The door sizing guide for kit codes is as follows:

Single timber door leaf			Double timber door leaf
Up to 2130mm high	Product Code		Up to 2130mm high	Product Code
400 - 926mm	E10 C		400 - 926mm	E10 DD C
927 - 1220mm	E20 C		927 - 1220mm	E20 DD C
1221 - 1650mm	E30 C		1221 - 1650mm	E30 DD C
Up to 2850mm high			Up to 2850mm high
400 - 926mm	E11 C		400 - 926mm	E11 DD C
927 - 1220mm	E22 C		927 - 1220mm	E22 DD C
1221 - 1650mm	E33 C		1221 - 1650mm	E33 DD C

NB. The following optional extras are not compatible with each other:

- Touch Latch and Soft Open & Close

- Simultaneous opening with either Touch Latch, Soft Close or Soft Open & Close
